109 Full Hood Stick Frame Set
£550.00 – £970.00
The 109 series 2/3 LWB frame has all you need to fit a soft top to your land rover including all nuts, bolts and hooks; this kit does not include the side and tail hooks which are usually factory fitted to your vehicle. If you do not have these then please state this when ordering so we can supply you with the correct amount, for the 109 you will require 10 side hooks.
Best way to identity your land rover Is to check how many hooks your windscreen has, for the 109” you will have 7 hooks.
Our frame kits are all proudly manufactured in the UK. With over 40 years’ experience working in the industry, we have been able to adapt and enhance our frames to ensure the perfect fit for your Land Rover type.
The frames are sourced from the UK and are as original as possible including 25mm 100% steel tubes with a 1mm wall and zinc galvanising to stop any rusting. All our frames are manufactured to fit canvas and mohair hoods (we can supply manufacture these as well). We can also supply these frames in black, the parts are galvanised first, rubbed down, primed and black powder coated for 2 layers of protection and finish. Heavy duty frames are becoming more popular in recent years and we have these available also both in Galvanised and Black finishes.
At AWT we understand that there are a multitude of ways you can modify your Land Rover and we can be flexible to cater for these modifications if you give us a call or email to let us know!
Your Kit Includes:
| 1x Over Screen Rail 2x Overdoor Panels LH/RH 2x Back of Door Panels LH/RH 1x Front Hoop 1x Middle Hoop 1x Rear Hoop 4x Tie Bars | 4x Claw Hooks 2x Corner Plates LH/RH 2x Horse Shoe Hooks 2x Rope Hooks LH/RH 4x Staples 4x 8mm Bolts 6x Flat Head Bolts 4x Phillips Bolts 18x 6mm Bolts | 6x Square Nuts 36x 6mm Washers 8x 8mm Washers 24x 6mm Nylocks 4x 8mm Nylocks 4x Nut Plate 50x Pop Rivets |
Additional information
| Weight | 30 kg |
|---|---|
| Dimensions | 155 × 18 × 96 cm |
| Finish | Black, Galvanised |
| 88/109 Header rail | Steel |
| Hoops and tubes | Steel |
| Over door panels | Steel |
| Back of door panels | Steel |
| Galvanising | Zinc |
| Nuts & bolts | Cadmium plated |
